Stihl AP 20.0 BATTERY

MPN: 48504003536

SKU: 7Q48504006536



AP 20 Battery: Lithium-Ion 144 Wh battery

36 V, 4.0 Ah Lithium-Ion battery. The AP 20 is an entry-level battery that powers some tools within the STIHL AP System.

With an energy capacity of 144 Wh, the battery has an integrated LED charge indicator, clearly displaying as and when the battery needs charging.

Ideal for lighter gardening and landscaping tasks, the AP 20 is suitable for domestic, semi-professional and professional users. Durable and IPX4 rated for all weather conditions, the AP 20 delivers long working times whilst offering a cost-effective way of powering entry level AP System tools.

This battery has a cold start feature, which protects the cells by warming them up in a controlled way before delivering full power and allows them to work down to -20° Celsius.

AP System batteries feature intelligent battery management system - this clever technology gives a constant level of power whether the battery is 100% charged or 1% charged.

Compatible with the AL 101, AL 301, AL 301-4 and AL 501 charger unit. For a full list of STIHL battery-powered tool working times, click here.

Features

When using other brands of battery tools, the performance can sometimes decrease during work as the battery discharges. This isn't the case with STIHL battery-powered tools. Thanks to the intelligent electronics, your tool will work with consistently high power across the entire battery charge, until there is no energy left in the battery.

SPLASHWATER PROTECTION. The AP 200 S is IPX4 certified thanks to the encapsulated electronics and sealing of each individual cell. It means that the battery is protected against splashwater from all sides and can be used in rainy conditions.

MAXIMUM PERFORMANCE INCREASE. Thanks to intelligent electronics, STIHL power tools and batteries communicate with each other. If the device and battery are equipped with the POWER BOOST function, the battery always provides the maximum possible power for the respective application. In order to ensure optimum battery life, the device temporarily adjusts the power if it is used too intensively.

The AP 20 will give you full power / reduced power when used with the following tools:



Full power
FSA 86FSA 90HLA 66HLA 86HSA 66
HSA 86HSA 100HSA 130HSA 140HSA 150
KGA 770SEA 100SHA 140--



Reduced power
BGA 86BGA 100BGA 160FSA 110FSA 120
FSA 130FSA 135HLA 135HTA 66HTA 86
HTA 135HTA 150HTA 160KMA 120KMA 135
MSA 161 TMSA 190 TMSA 220 T--

Technical details

Rated voltage36 V
Battery weight1.29 kg
Energy content144 Wh
Rated capacity as per IEC 619603.9 A·h
Rated cell capacity (as per manufacturer data)2 A·h
Number of LEDs4 PC

Got a question? 01293 820088

£155.57 inc VAT

Estimated lead time 5 to 7 days

Collect from our store at RH1 5EQ. We will contact you as soon as your order is ready.

We offer same day local delivery to postcodes RH1-2, RH6, RH10-12. Orders must be placed by 12pm. Delivery cost is £15 incl VAT.

Next business day delivery on orders over £150 inc VAT is £6.98. Delivery for orders below £150 is £7.99. Orders must be placed by 3pm.

FREE standard delivery (2 - 3 business days) on orders over £150 inc VAT. Delivery for orders below £150 is £5.99 inc VAT.

Please see our returns information here.

Technical Information

  • Brand: Stihl
  • Type: Battery
  • Voltage: AP 36
