Leica Rugby 680 USB C & Rod Eye 160 Kit

Technical Details

Bring simplicity to construction applications with the Leica Rugby 680 semi-automatic grade lasers. Designed for contractors who do mostly flat work but occasionally need to create single or dual slopes, Rugby 680 construction lasers are easy to use and effective in all levelling and grading tasks.

Product Highlights

• Range 800m Diameter
• Digital slope in dual axis
• Rotation 10 rps
• Beam down & sleep mode
• Grade range ± 8% DG
• Accuracy 1.5mm at 30m
• IP67: sealed against water

Features

• A great general construction laser with digital grade capability
• Dial-in grade in single or dual axis, easy and fast at the touch of a button
• The unique Smart Slope function continuously monitors time and temperature changes to ensure accurate performance over the course of the day
• The product casts a horizontal laser plane or a laser beam for the purpose of alignment.
• The laser beam can be detected by means of a laser detector.
• Data communication with external appliances.

Slopes done easily

• Easily perform levelling and slope applications with the semi-automatic Leica Rugby 680 dual and single grade lasers. Their simple user interface, four-button menu and digital display allow quick and convenient dial-in grade for increased productivity and efficiency on site.
• The Rugby 680 laser is protected to IP67 dust and water protected and has a glass cage and tough housing which gives ultimate protection. It has rubber handles for grip, a large high contrast LCD display and a simple, easy to understand user interface. H-I and Bump alert feature alerts the operator of any disturbances and when the grade is used the smart slope function will continue to monitor in order to make sure accurate time and temperature results are provided all day long.

Accurate performance throughout the day

• Eliminate costly errors and downtime coming from temperature changes on the jobsite. The Smart Slope function of the Rugby 680 continuously monitors temperature changes over time. This unique functionality assures accuracy and solid laser performance over the course of the day.

Comes With

• Rod Eye 160 Receiver
• Staff up to 4m
• Construction Tripod 1-1.6m
• User manual on CD
• Quick start guide
• Safety instructions
• Protect by Leica Geosystems card.
• Producer inspection certificate
• Carry case
• 4 x D Cell Disposable Batteries (50+ Hours run time)
• D Cell Battery Tray
• 3 Year warranty

Product Information

Product  LEICA RUGBY 680 OUTDOOR LASER LEVEL KIT WITH ROD EYE 160 RECEIVER

Functionality  Self-Levelling Horizontal with Dual-In, Dual Axis, Semi-Auto Slope

Semi-Auto Grade Range  ± 8% DG

Range (Diameter)  600m with RE Basic 1100m with RE 140/160

Self-levelling accuracy  ± 1.5mm at 30m (± 1/16" at 100ft)

Self-levelling Range  ± 5°

H.I elevation alert/Bump alert  YES

Rotation Speeds  10 rps

Laser Diode Type Class  635nm Class 2

Battery Life (Alkaline)  50+ hours @ 20 °C

Battery Type (Alkaline)  Four D-cells

Protection Class (Splash water/Dust Proof)  IP 67

Operating Temperature  20 to +50 °C (4 to +122 °F)

Weight with Batteries  2.6 Kg
